Mak Health Sliding Door

MakHealth is a hermetically sealed sliding door. (Sliding Direction: Horizontally trom Left or Right)

  • Can withstand upto 100Pa overpressure.
  •  60mm thick door panel with 4mm thick HPL on both sides
  •  Hermetic sealing, energy efficient, easy operation
Request advice

Mak Health hermetic sealed sliding doors are ideal for application in critical areas like OT room, ICU and other places like post-operative rooms and passage areas.

It is 100% hermetic sealed in compliance to EN 12207 standards.  It prevents from cross contamination and saves cost on clean air by reducing the time for building the air pressure inside the OT. Its features like touchless operation makes it not only completely safe from any bacterial transfer but also gives ease of operation.

  • Can withstand upto 100Pa overpressure.
  • 60mm thick door panel with 4mm thick HPL on both sides.
  • Hermetic sealing, energy efficient, easy operation.
  • Flush door, door skin is made o f jointless laminates for widths upto 1500mm.
  • Removable EPDM sealing gasket.
  • Available in sizes from 1200 x 2100mm to 1800 x 2100mm
  • Other sizes available on request
  • Customization as per client’s requirement..
Show more Show less

Options

The MAK Health sliding door offers the following options:

Airtight
Door system is airtight
Noise reducing
Door system can be made noise-reducing
Smoke-proof
Door system is smoke-proof
Smooth finishing
Door leaf has a completely smooth finishing

Product specifications

Type
Sliding door
Operation
Automatic, Manual
Door leaf
The door leaf has thickness of 60mm with PIR core (CFC free)with high-pressure laminate (HPL) on both sides confirming to EN 438- 3:2005. The door profile are flushed with door leaf in Aluminium Alloy, Grade 6063, Temper T6 natural anodized finish.
Sealing
Easily replaceable all around EPDM gasket. When closed, the EPDM gasket is pressed against the frame to make sure perfect sealing.
Wall frame
Aluminium Alloy, Grade 6063, Temper T6 in Natural Anodized 20 μm.
Vision Panel
Double Glazed IG unit with 5mm tempered glass on both sides.
Noise insulation
28 db
Air Permeability
Air tightness to an overpressure of upto 100 Pa
Rollers
Special Grade Self-lubricating PA
Lever handle
Solid AISI 304 Grade Stainless Steel with rubber spring system
Rail
Aluminium Alloy, Grade 6063, Temper T6. Natural Anodized. single length upto 1800mm wide doors. 45° indentations with simultaneous “down and in” movement.
